Spectrum PET-G FR V0
Professional Flame Retardant | UL94 V0 Compliant
Spectrum PET-G FR V0 is a high-performance, flame-retardant filament engineered for critical industrial applications where fire safety is the top priority. Based on a premium PET-G matrix, this material has been chemically modified with halogen-free additives to achieve a V0 flammability rating according to the UL94 standard (at 1.5mm thickness).
Unlike standard plastics, Spectrum PET-G FR V0 is self-extinguishing, meaning it stops burning almost immediately after the flame source is removed. This makes it the essential choice for the 3D printing of electronic components, battery housings, and any part installed in public transport or industrial environments.
Many traditional fire retardants use halogens which release toxic, corrosive smoke when heated. Spectrum PET-G FR V0 is halogen-free, ensuring that in the event of high heat, it remains safer for human health and prevents acid-smoke damage to sensitive electronic circuitry.
🚒 Self-Extinguishing Power
Certified V0 rating ensures vertical burning stops within 10 seconds without any flaming drips.
⚡ Electrical Safety
Excellent dielectric properties make it ideal for insulators, connectors, and cable management systems.
🛡️ Chemical & Impact Toughness
Retains the famous PET-G durability, offering resistance to moisture and industrial chemicals.
📉 Low Warpage & Shrinkage
Easy to print even for large-scale enclosures, providing high dimensional accuracy for tight assemblies.
- Electronic enclosures and distribution boxes
- Battery covers and EV charging components
- Connectors, insulators, and circuit breakers
- Interior components for trains, buses, and aircraft
- Public space lighting and signage hardware
- Industrial sensor mounts in high-heat areas
| Material Identity & Compliance | |
|---|---|
| Producer / Series | Spectrum Filaments / PET-G FR V0 |
| Material Type | Flame-Retardant Modified PET-G |
| Filament Diameter | 1.75 mm ± 0.05 mm |
| Flammability Rating | UL94 V0 (at 1.5 mm thickness) |
| Color | Tactical Black/NATURAL |
| Net Weight | 0.75 kg |
| EAN / SKU | 5903318301143 / 80112 |
| Nozzle Temperature | 235 - 255°C |
| Heated Bed Temperature | 80 - 100°C |
| Cooling Fan | 0 - 25% (Low for best layer adhesion) |
| Drying Recommended | Yes (60°C for 4 hours) |
| Retraction Speed | 35 - 45 mm/s |
| Enclosure | Recommended for large parts (temp stability) |
| Net Weight [kg] | Spool Type | Sealant | Standard Compliance |
|---|---|---|---|
| 0.75 | Standard Industrial Spool | Vacuum + Desiccant | RoHS & REACH Halogen-Free |
Ensure your project meets regulatory requirements by accessing the official data:
* Critical Note for Compliance: To achieve the full UL94 V0 fire protection rating, the 3D printed wall thickness must be at least 1.5mm. Using fewer perimeters or thin walls may compromise the self-extinguishing performance of the material.
